THE NEXT GENERATION OF LIGHTING

The FNG series combines power, intensity and style in a redesigned compact build. Level up your driving experience with advanced optics, controlled beam patterns, and intense brightness. Crafted and designed to provide the performance when you need it!

FEATURES

High-Intensity Osram LEDs: The FNG series is our Biggest and Brightest light pod ever! Each circuit board is composed of 4x 5W high-intensity Osram LED chips.

IP67 Waterproof Rate: FNG 3” Series meets the IP67 water and standard dust proof rate. It is 100% protected against solid objects like dust and sand. It has been tested to work for at least 30 minutes under 1m of water.

Thermal Management: Unlike other designs, the FNG series are equipped with large heat fins that allow the LED chips to cool properly for extended use. Engineered to perfection the FNG Series will brighten your adventures to the max.

TIR Optic Technology: The TIR (Total Internal Reflection) is an internal lens within the light housing. It captures and emits more light directly from the LED chip than your traditional light housing (such as a parabolic reflector).

BEAM PATTERNS

Hyper Spot: The beam pattern is best used for maximum distance in off-road or racing applications. The beam pattern is concentrated in a circular hotspot straight ahead of the vehicle. These can be very effective for off-road high-speed motor vehicles. The Intense series Hyper Spot cubes give you the off-road reassurance you need.

Wide Flood: Creates a large vast and tall soft beam pattern. The best suitable application would be used for work lights or reverse backup lights.

DIMENSIONS

FNG 3 Products Details

FNG 3 info sheet

PART NUMBER: 10410 10420 10310 10320 12410 12310
QUANTITY: 1 FNG Intense Light Pods 1 FNG Intense Light Pods 1 FNG Intense Light Pods 1 FNG Intense Light Pods 1 FNG Intense Light Pods 1 FNG Intense Light Pods
LIGHT OUTPUT: 2000 Lumens (Per Light) 2000 Lumens (Per Light) 2000 Lumens (Per Light) 2000 Lumens (Per Light) 2000 Lumens (Per Light) 2000 Lumens (Per Light)
DIMENSIONS: 3.0” x 3.0” x 2.6” 3.0” x 3.0” x 2.6” 3.0” x 3.0” x 2.6” 3.0” x 3.0” x 2.6” 3.0” x 3.0” x 2.6” 3.0” x 3.0” x 2.6”
OPTICS: Spot Spot Flood Flood Spot Flood
COLOR: White Amber White Amber White White
SHAPE Standard Standard Standard Standard Flush Mount Flush Mount
LED CHIP: Osram Osram Osram Osram Osram Osram
WATTS: 20w 20w 20w 20w 20w 20w
CURRENT: 1.6A @12v 1.6A @12v 1.6A @12v 1.6A @12v 1.6A @12v 1.6A @12v
IP RATING: IP67 IP67 IP67 IP67 IP67 IP67
WARRANTY: 7 Years 7 Years 7 Years 7 Years 7 Years 7 Years
UPC: 628242450771 628242450875 628242450770 628242450874 628242450781 628242450780

  • 1x FNG Intense Pod Light
  • 1x Mounting bracket with stainless steel hardware





Customer Reviews

Based on 21 reviews
100%
(21)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
B
Bobby Brown
Work great, hold up.

Hold up in averse conditions

S
Sean

Great lights and easy to install! Highly recommend them or anything from Vivid Lumen for that matter!

M
Mike
Bright as can be and quality product

Best quality/price ever highly recommend 🤙

E
Earl Z.
FNG3 ftw!

Because all the other named brands are a bunch of cash grabs, enter Vivid Lumen, right for the budget, street legal and does the job without blinding the oncoming traffic or the car I'm following. Lights up my world. I have them in my winch bumper for my 3rd gen 4Runner as driving/fog lights paired with the Auxbeam light control panel. Looking into getting another pair of hyper-spot beam pattern for my ditch lights. The only downside is I didn't get any Vivid Lumen stickers/decal with my order.

C
C.W.
Absolutely love all my fng 3!

So far I’ve got 2 floods on the hood and created a little light bar in the bumper with 3 floods and 2 spot lights. I have street legal series on the way which will mount in the factory fog light space. Really love the service you get from these guys at vivid lumens and Ryan has been extremely helpful and great to deal with!
