THE NEXT GENERATION OF LIGHTING
The FNG series combines power, intensity and style in a redesigned compact build. Level up your driving experience with advanced optics, controlled beam patterns, and intense brightness. Crafted and designed to provide the performance when you need it!


FEATURES
High-Intensity Osram LEDs: The FNG series is our Biggest and Brightest light pod ever! Each circuit board is composed of 4x 5W high-intensity Osram LED chips.
IP67 Waterproof Rate: FNG 3” Series meets the IP67 water and standard dustproof rate. It is 100% protected against solid objects like dust and sand. It has been tested to work for at least 30 minutes under 1m of water.
Thermal Management: Unlike other designs, the FNG series are equipped with large heat fins that allow the LED chips to cool properly for extended use. Engineered to perfection the FNG Series will brighten your adventures to the max.
TIR Optic Technology: The TIR (Total Internal Reflection) is an internal lens within the light housing. It captures and emits more light directly from the LED chip than your traditional light housing (such as a parabolic reflector).
BEAM PATTERNS
Hyper Spot: Designed for off-road or racing applications, the Hyper Spot beam pattern offers maximum distance. The concentrated circular hotspot illuminates straight ahead of your vehicle, making it ideal for off-road high-speed motor vehicles. With the FNG 3 Intense Pod's Hyper Spot cubes, experience the off-road reassurance you crave.
Wide Flood: Enjoy a wide, vast, and tall soft beam pattern with the Wide Flood option. Perfect for work lights or reverse backup lights, this beam pattern ensures optimal visibility in various applications.
DIMENSIONS



PART NUMBER: | 10410 | 10420 | 10310 | 10320 | 12410 | 12310 |
QUANTITY: | 1 FNG Intense Light Pods | 1 FNG Intense Light Pods | 1 FNG Intense Light Pods | 1 FNG Intense Light Pods | 1 FNG Intense Light Pods | 1 FNG Intense Light Pods |
LIGHT OUTPUT: | 2000 Lumens (Per Light) | 2000 Lumens (Per Light) | 2000 Lumens (Per Light) | 2000 Lumens (Per Light) | 2000 Lumens (Per Light) | 2000 Lumens (Per Light) |
DIMENSIONS: | 3.0” x 3.0” x 2.6” | 3.0” x 3.0” x 2.6” | 3.0” x 3.0” x 2.6” | 3.0” x 3.0” x 2.6” | 3.0” x 3.0” x 2.6” | 3.0” x 3.0” x 2.6” |
OPTICS: | Spot | Spot | Flood | Flood | Spot | Flood |
COLOR: | White | Amber | White | Amber | White | White |
SHAPE | Standard | Standard | Standard | Standard | Flush Mount | Flush Mount |
LED CHIP: | Osram | Osram | Osram | Osram | Osram | Osram |
WATTS: | 20w | 20w | 20w | 20w | 20w | 20w |
CURRENT: | 1.6A @12v | 1.6A @12v | 1.6A @12v | 1.6A @12v | 1.6A @12v | 1.6A @12v |
IP RATING: | IP67 | IP67 | IP67 | IP67 | IP67 | IP67 |
WARRANTY: | Lifetime | Lifetime | Lifetime | Lifetime | Lifetime | Lifetime |
UPC: | 628242450771 | 628242450875 | 628242450770 | 628242450874 | 628242450781 | 628242450780 |
- 1x FNG Intense Pod Light
- 1x Mounting bracket with stainless steel hardware
